Welcome


myCNC Applications

Mill

Plasma

Tangential Cutting

Oxy-fuel

Laser

CNC Vision

myCNC  is a multi-platform CNC Control Software that can be installed on MS Windows (7, 8, 10), Linux, and Embedded Linux Operating systems. myCNC can be run on Desktop PC, Industrial PC, Laptop or Single Board Computer (SBC) like a Raspberry Pi, Odroid-C2/XU4, Asus TinkerBoard, Rock64, Cubieboard2 and others.

myCNC features a simultaneous 4-axes motion control with S-curve speed profile for smooth machine motion, G-code with Macro Language extension support, built-in PLC controllers and a built-in PLC Builder IDE for flexible peripherals control.

myCNC supports special-purpose G/M codes for a wide range of applications - mill, lathe, routers, tangential knife, plasma, oxy-fuel, laser cutting, Torch Height Control (THC), and ATC.  myCNC also features a fully customizable GUI, an advanced 2D/3D visualization, and real-time IO monitoring.

For a full overview of myCNC features, please consult our Main Features page.

All of our technical manuals and setup guides are available on our Documentation Wiki.



Electronic Kits

We offer a number of CNC Motion Control electronic kits, which include:

  • CNC Ethernet Motion Control board - one of ET6, ET7, ET10, ET15 (under development)
  • TFT screen electronics kit (10.1" / 15.6" IPS Full HD 1920*1080 panel, eDP to HDMI driver board, eDP flex cable, HDMI cable, 10.1" / 15.6" 5-wire resistive touch screen, eGalax USB touch screen driver board with a USB cable)
  • Single board computer with Linux OS (Ubuntu Mate 16.04 or Armbian) and myCNC CNC Control software installed, such as:
    • Odroid-C2 computer board (ARMv8 64 bit, 1500MHz 4 Core CPU, 2G RAM, 16G Flash (microSD class U1), USB Wifi)
    • ASUS Tinkerboard computer board (ARM 32 bit, 1800MHz 4 Core CPU, 2G RAM, 16G Flash (microSD class U1), USB Wifi)
  • Wireless Pendant control and myCNC control software are compatible with popular pendant models such as:
    • XHC WHB02 (in stock),
    • XHC WHB04L,
    • XHC PHB02 (in stock)
    • XHC PHB02,
    • XHC PHB02B,
    • XHC PHB03S,
    • XHC PHB04B-6 (in stock)
  • CNC Vision camera kits
  • Optional operator panel (for the ET7 controller only). ET7 control board has a connector for optional Operator panel keyboard. The board contains
    • 21 keys (fully customized in the Control software)
    • 2 rotary encoder (customized)
    • 1 double axis analogue resistive joystick for XY jogging

 For a full overview of our kits, please visit the Ethernet CNC electronic kits page.

Download

Customized LiveCD Ubuntu Mate 18.04LTS with installed myCNC software

The LiveCD is in beta-testing, provided AS IS. A manual on LiveCD installation is available on our Documentation Wiki.

Release date Description
2020 Jun 29

Ubuntu Mate 20.04 LTS + myCNC

Changelog: New release. Beta testing. Ubuntu 20.04 LTS

2019 Dec 06

Ubuntu Mate 18.04.3 + myCNC

Changelog:

  • Ubuntu updated to 18.04.3 LTS
  • eGalax touch screen drivers are added and ready to install
  • Anydesk software ready

 myCNC software installation packages

NOTE: We strongly encourage users to utilize out Ubuntu MATE image provided above.

Release date Linux
32bit(x86_32) 64bit(x86_64)
Windows 7, 32bit Windows 7, 64bit

Windows 10, 64bit

Windows 10, 32bit

ARM Linux 32 bit
(Asus Tinkerboard,
Raspberry Pi4)
ARM Linux 64 bit
(Odroid-C2)

2022 May 31 myCNC-1.88.5469 myCNC-1.88.5449 myCNC64-1.88.5469 myCNC 64bit Win10 1.88.5658 Follow instructions on the Downloads page



For a full list of downloads, please visit the Downloads page.
